Aluminum Oil Level Sight Glass With Plexiglass
Sight glass, Oil level sight glass, liquid Sight Glass, Oil level indicator, Viewport
Material
Body: Aluminum
O-Ring: NBR
Window: Tempered Borosilicate GlassPlexiglass
Usage: Pump Gearboxes, Speed Reducer, Compressor and Power Transmission.
Size；
G 1/2'',G 3/4''
NPT 1/2‘’,NPT 3/4‘’,
|
ITEM |
G |
D |
d |
L |
L2 |
L1 |
HEX |
|
WO-OSG-11-M01 |
M10*1 |
16 |
5 |
15 |
3 |
8 |
13 |
|
WO-OSG-11-M02 |
M14*1.5 |
20 |
8 |
18 |
4 |
9 |
17 |
|
WO-OSG-11-M03 |
M16*1.5 |
22 |
10 |
18 |
4 |
9 |
19 |
|
WO-OSG-11-M04 |
M18*1.5 |
25 |
11.5 |
18 |
4 |
9 |
21 |
|
WO-OSG-11-M05 |
M20*1.5 |
27 |
12.5 |
18 |
4 |
9 |
23 |
|
WO-OSG-11-M06 |
M22*1.5 |
28 |
13.5 |
18 |
4 |
9 |
23 |
|
WO-OSG-11-M07 |
M27*1.5 |
32 |
20 |
18 |
4 |
9 |
26 |
|
WO-OSG-11-M08 |
M33*2.0 |
40 |
23.5 |
24 |
4 |
13 |
34 |
|
WO-OSG-11-M09 |
M42*2.0 |
50 |
30 |
24 |
11 |
13 |
/ |
|
WO-OSG-11-M11 |
M48*2.0 |
55 |
38 |
24 |
11 |
13 |
/ |
|
|
|||||||
|
ITEM |
G |
D |
d |
L |
L2 |
L1 |
HEX |
|
WO-OSG-11-G01 |
G1/4’’ |
20 |
8 |
18 |
4 |
9 |
17 |
|
WO-OSG-11-G02 |
G3/8’’ |
22 |
10 |
18 |
4 |
12 |
19 |
|
WO-OSG-11-G03 |
G1/2’’ |
28 |
13.5 |
22 |
4 |
12 |
23 |
|
WO-OSG-11-G04 |
G3/4’’ |
32 |
20 |
22 |
4 |
13 |
26 |
|
WO-OSG-11-G05 |
G1’’ |
40 |
23.5 |
24 |
4 |
13 |
34 |
|
WO-OSG-11-G06 |
G1 1/4’’ |
50 |
30 |
24 |
11 |
13 |
/ |
|
WO-OSG-11-G07 |
G1 1/2’’ |
55 |
38 |
24 |
11 |
13 |
/ |
